Installation Guide – Nextone Taupe 24×48 3/4 Porcelain Paver – Natural
Important Advisory
This guide provides general installation information for the Nextone Taupe 24×48 3/4 Porcelain Paver. Before installation, confirm that the selected installation method, application, substrate, drainage design, and project conditions are approved for this product. Follow current Happy Floors instructions, applicable local building codes, recognized TCNA/ANSI standards, and the requirements of the selected installation-system manufacturer.
Step 1: Layout & Planning
- Inspect all pavers before installation. Confirm the color, caliber, thickness, finish, edge condition, and quantity, and review material from multiple boxes before setting.
- Dry-lay representative pavers to establish the layout, balance perimeter cuts, and coordinate the rectangular format with transitions and adjacent materials.
- Establish reference lines with a chalk line or laser and plan joint widths, perimeter clearances, movement accommodation, and transitions according to the selected installation system.
- For exterior installations, verify that the supporting design provides appropriate drainage away from buildings and other structures before placing the pavers.
Step 2: Paver Installation
- Prepare a stable, properly engineered substrate or base suitable for the selected porcelain paver installation method. Verify support, compaction where applicable, drainage, load requirements, and surface tolerances before installation.
- Use only a setting or support system specifically approved for this product, the intended application, and the project conditions. Do not assume that sand-set, mortar-set, pedestal, or other installation methods are interchangeable or approved without confirmation.
- Provide uniform support beneath each paver and handle the 24×48 format with suitable equipment and adequate assistance to reduce movement, cracking, or damage.
- Maintain consistent joints appropriate for rectified porcelain pavers and the selected installation method. Do not install pavers tightly edge to edge.
- Check alignment, elevation, surface drainage, and joint consistency throughout the installation. Provide movement joints and perimeter accommodation as required by the project design and applicable standards.
Step 3: Cutting
- Use professional cutting equipment and a diamond blade rated for porcelain pavers and capable of safely accommodating the 24×48 format.
- Support the full paver during handling and cutting to reduce cracking and edge chipping. Measure each cut carefully, accounting for joint widths, perimeter clearances, and movement spaces.
- Use appropriate eye, hearing, hand, and respiratory protection, and control silica-containing dust in accordance with applicable safety requirements.
- Inspect cut edges before installation and do not place cracked or damaged pieces in service.
Step 4: Joint Filling
- Use a jointing or grout material compatible with porcelain pavers, the selected installation method, the joint width, and the project conditions.
- Allow setting materials to cure according to the applicable manufacturer instructions before applying grout or other jointing material.
- Provide movement joints where required and use compatible flexible sealants at designated movement locations. Do not fill movement joints with rigid grout.
- Remove excess grout, jointing material, and installation residue promptly using cleaning methods approved for the porcelain surface.
Step 5: Cleaning & Maintenance
- Remove construction residue and grout haze according to the recommendations of the setting-material and cleaning-product manufacturers.
- Clean routinely with water, a pH-neutral cleaner suitable for porcelain, and non-abrasive tools.
- Avoid harsh chemicals, abrasive tools, and products that are not approved for porcelain or the installed joint materials.
- Periodically inspect exterior joints, transitions, drainage paths, and the supporting installation system where applicable.
Disclaimer
Stone Market USA provides this installation guide for general planning purposes only. Installation suitability depends on the product, substrate, supporting structure, climate, intended use, and selected installation method. Consult Happy Floors, the installation-system manufacturer, and a qualified installation professional before proceeding. Inspect all material before installation and follow applicable codes and recognized industry standards.
